Assembly and Packaging is performed in the clean room of Class 10. Valves are packed with anti-static polyethylene bag that is pressured into the high purity nitrogen gas.
Applications:
Cleaning & Testing– Passivation is done at Nitrogen environment. Fine cleaning is done by Ultrasonic cleansing with resistivity over 18M.Q D.I. water after finishing the passivation. Inboard helium leak tested to a rate of 4 x 109cm3/s
| Product | O.D. (in) | Orifice (in) | Orifice (mm) | End Connection Type | Body Material | Cv | Dimension L (mm) | Dimension H1 (mm) | Dimension H2 (mm) | Dimension P (mm) | Dimension R (mm) | Dimension T (mm) | |
| BLSV1VM-4 | 1/4 | 0.157 | 4.00 | Male 2CR Fitting | 316L Stainless Steel | 0.30 | 58.50 | 14.00 | 41.80 | 88.60 | 83.40 | 80.30 | |
| BLSV2VM-8 | 1/2 | 0.276 | 7.00 | Male 2CR Fitting | 316L Stainless Steel | 0.65 | 65.00 | 16.00 | 45.80 | 92.60 | 87.40 | 84.30 | |
| BLSV1H-4 | 1/4 | 0.157 | 4.00 | Hy-Lok Tube Fitting | 316L Stainless Steel | 0.30 | 62.50 | 14.00 | 41.80 | 88.60 | 83.40 | 80.30 | |
| BLSV1H-6 | 3/8 | 0.157 | 4.00 | Hy-Lok Tube Fitting | 316L Stainless Steel | 0.30 | 65.50 | 14.00 | 41.80 | 88.60 | 83.40 | 80.30 | |
| BLSV2H-6 | 3/8 | 0.276 | 7.00 | Hy-Lok Tube Fitting | 316L Stainless Steel | 0.65 | 65.50 | 14.00 | 41.80 | 88.60 | 83.40 | 80.30 | |
| BLSV2H-8 | 1/2 | 0.276 | 7.00 | Hy-Lok Tube Fitting | 316L Stainless Steel | 0.65 | 71.10 | 14.00 | 41.80 | 88.60 | 83.40 | 80.30 | |
| BLSV1VF-4 | 1/4 | 0.157 | 4.00 | Female ZCR Fitting | 316L Stainless Steel | 0.30 | 70.10 | 11.40 | 41.80 | 88.60 | 83.40 | 80.30 | |
| BLSV2VF-8 | 1/2 | 0.276 | 7.00 | Female ZCR Fitting | 316L Stainless Steel | 0.65 | 80.00 | 16.00 | 45.80 | 92.60 | 87.40 | 84.30 | |
| BLSV1BW-4 | 1/4 | 0.157 | 4.00 | Tube Butt Weld | 316L Stainless Steel | 0.30 | 44.20 | 11.40 | 41.80 | 88.60 | 83.40 | 80.30 | |
| BLSV1BW-6 | 3/8 | 0.157 | 4.00 | Tube Butt Weld | 316L Stainless Steel | 0.30 | 44.20 | 11.40 | 41.80 | 88.60 | 83.40 | 80.30 | |
| BLSV2BW-6 | 3/8 | 0.276 | 7.00 | Tube Butt Weld | 316L Stainless Steel | 0.65 | 44.20 | 14.00 | 41.80 | 88.60 | 83.40 | 80.30 | |
| BLSV2BW-8 | 1/2 | 0.276 | 7.00 | Tube Butt Weld | 316L Stainless Steel | 0.65 | 44.20 | 14.00 | 41.80 | 88.60 | 83.40 | 80.30 |
