| Product | Pipe Size | Flow Coefficient (Cv) | Minimum Orifice (in) | Minimum Orifice (mm) | Length (L) (in) | Length (L) (mm) | Width Across Flat (H) (in) | Width Across Flat (H) (mm) | |
| QF1NF-4N | 1/4-18 NPT | 1.7 | 0.240 | 6.10 | 1.600 | 40.60 | 3/4 | 19.00 | |
| QF1NF-6N | 3/8-18 NPT | 1.7 | 0.240 | 6.10 | 1.670 | 42.40 | 7/8 | 22.20 | |
| QF2NF-6N | 3/8-18 NPT | 7.1 | 0.470 | 11.90 | 1.590 | 40.40 | 1 1/16 | 26.90 | |
| QF2NF-8N | 1/2-14 NPT | 11.5 | 0.500 | 12.70 | 1.820 | 46.20 | 1 1/16 | 26.90 | |
| QF3NF-12N | 3/4-14 NPT | 23.6 | 0.720 | 18.30 | 2.080 | 52.80 | 1 5/16 | 33.30 | |
| QF4NF-16N | 1-11.5 NPT | 39.0 | 0.880 | 22.40 | 2.490 | 63.20 | 1 5/8 | 41.20 | |
| QF1NF-4R | Rc 1/4 | 1.7 | 0.240 | 6.10 | 1.600 | 40.60 | 3/4 | 19.00 | |
| QF2NF-8R | Rc 1/2 | 11.5 | 0.500 | 12.70 | 1.820 | 46.20 | 1 1/16 | 26.90 | |
| QF1NF-4G | G 1/4 | 1.7 | 0.240 | 6.10 | 1.600 | 40.60 | 3/4 | 19.10 | |
| QF2NF-8G | G 1/2 | 11.5 | 0.500 | 12.70 | 1.820 | 46.20 | 1 1/16 | 26.90 |
