Union Ball Joint

  • Precision pipe fittings for instrumentation and process control
  • Fine threads constructed to ensure leak-free & reliable systems
  • Male threads are protected with plastic cap
  • Various materials including SS316, Brass and Carbon steel
  • Many choice of connections and configurations are available
  • Female NPT both ends
Contact us
Find a distributor
SKU N/A Category

Description

Product Dimension A (mm) Dimension E (mm) Dimension H (Hex) (mm) Dimension H₁(Hex) (mm) Pipe Size (in) PDF
H-SUR-2N-BRAS 45.7 6.90 28.60 23.80 1/8 PDF
H-SUR-4N-BRAS 59.4 9.10 34.90 30.20 1/4 PDF
H-SUR-6N-BRAS 63.5 13.20 38.10 33.30 3/8 PDF
H-SUR-8N-BRAS 68.6 15.70 44.50 41.30 1/2 PDF
H-SUR-12N-BRAS 79.2 22.40 50.80 47.60 3/4 PDF
H-SUR-16N-BRAS 90.4 26.20 63.50 60.30 1 PDF
H-SUR-2N-STEL 45.7 6.90 28.60 23.80 1/8 PDF
H-SUR-4N-STEL 59.4 9.10 34.90 30.20 1/4 PDF
H-SUR-6N-STEL 63.5 13.20 38.10 33.30 3/8 PDF
H-SUR-8N-STEL 68.6 15.70 44.50 41.30 1/2 PDF
H-SUR-12N-STEL 79.2 22.40 50.80 47.60 3/4 PDF
H-SUR-16N-STEL 90.4 26.20 63.50 60.30 1 PDF
H-SUR-2N-S316 45.7 6.90 28.60 23.80 1/8 PDF
H-SUR-4N-S316 59.4 9.10 34.90 30.20 1/4 PDF
H-SUR-6N-S316 63.5 13.20 38.10 33.30 3/8 PDF
H-SUR-8N-S316 68.6 15.70 44.50 41.30 1/2 PDF
H-SUR-12N-S316 79.2 22.40 50.80 47.60 3/4 PDF
H-SUR-16N-S316 90.4 26.20 63.50 60.30 1 PDF
