| Product | Dimension d (in) | Dimension d (mm) | Dimension D (in) | Dimension D (mm) | Dimension L (in) | Dimension L (mm) | Tube O.D. (mm) | Tube Wall Gage (t) | Wall Thickness (in) | Wall Thickness (mm) | |
| CHETP-8-11-14-BRAS | 0.280 | 7.10 | 0.366 | 9.30 | 1.550 | 39.40 | 12.7 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP-8-15-20-BRAS | 0.371 | 9.40 | 0.457 | 11.60 | 1.560 | 39.60 | 12.7 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP10-11-14-BRAS | 0.405 | 10.30 | 0.491 | 12.50 | 1.570 | 39.90 | 15.87 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP10-15-20-BRAS | 0.496 | 12.60 | 0.582 | 14.80 | 1.580 | 40.10 | 15.87 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP12-11-14-BRAS | 0.530 | 13.50 | 0.616 | 15.60 | 1.580 | 40.10 | 19.05 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP12-12-17-BRAS | 0.546 | 13.90 | 0.663 | 16.80 | 2.090 | 53.10 | 19.05 | 12 to 17 | 0.058 to 0.109 | 1.5 to 2.8 | |
| CHETP12-15-20-BRAS | 0.621 | 15.80 | 0.707 | 18.00 | 1.590 | 40.40 | 19.05 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP14-11-14-BRAS | 0.650 | 16.50 | 0.741 | 18.70 | 1.600 | 40.60 | 22.22 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP14-15-20-BRAS | 0.746 | 18.90 | 0.832 | 21.10 | 1.620 | 41.10 | 22.22 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP16-11-14-BRAS | 0.780 | 19.80 | 0.866 | 22.00 | 1.620 | 41.10 | 25.4 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP16-12-17-BRAS | 0.794 | 20.10 | 0.908 | 23.10 | 2.110 | 53.60 | 25.4 | 12 to 17 | 0.058 to 0.109 | 1.5 to 2.8 | |
| CHETP16-15-20-BRAS | 0.871 | 22.10 | 0.957 | 24.30 | 1.630 | 41.40 | 25.4 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP-8-11-14-STEL | 0.280 | 7.10 | 0.366 | 9.30 | 1.550 | 39.40 | 12.7 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP-8-15-20-STEL | 0.371 | 9.40 | 0.457 | 11.60 | 1.560 | 39.60 | 12.7 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP10-11-14-STEL | 0.405 | 10.30 | 0.491 | 12.50 | 1.570 | 39.90 | 15.87 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP10-15-20-STEL | 0.496 | 12.60 | 0.582 | 14.80 | 1.580 | 40.10 | 15.87 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP12-11-14-STEL | 0.530 | 13.50 | 0.616 | 15.60 | 1.580 | 40.10 | 19.05 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP12-12-17-STEL | 0.546 | 13.90 | 0.663 | 16.80 | 2.090 | 53.10 | 19.05 | 12 to 17 | 0.058 to 0.109 | 1.5 to 2.8 | |
| CHETP12-15-20-STEL | 0.621 | 15.80 | 0.707 | 18.00 | 1.590 | 40.40 | 19.05 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP14-11-14-STEL | 0.650 | 16.50 | 0.741 | 18.70 | 1.600 | 40.60 | 22.22 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP14-15-20-STEL | 0.746 | 18.90 | 0.832 | 21.10 | 1.620 | 41.10 | 22.22 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP16-11-14-STEL | 0.780 | 19.80 | 0.866 | 22.00 | 1.620 | 41.10 | 25.4 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP16-12-17-STEL | 0.794 | 20.10 | 0.908 | 23.10 | 2.110 | 53.60 | 25.4 | 12 to 17 | 0.058 to 0.109 | 1.5 to 2.8 | |
| CHETP16-15-20-STEL | 0.871 | 22.10 | 0.957 | 24.30 | 1.630 | 41.40 | 25.4 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP-8-11-14-S316 | 0.280 | 7.10 | 0.366 | 9.30 | 1.550 | 39.40 | 12.7 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP-8-15-20-S316 | 0.371 | 9.40 | 0.457 | 11.60 | 1.560 | 39.60 | 12.7 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP10-11-14-S316 | 0.405 | 10.30 | 0.491 | 12.50 | 1.570 | 39.90 | 15.87 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP10-15-20-S316 | 0.496 | 12.60 | 0.582 | 14.80 | 1.580 | 40.10 | 15.87 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP12-11-14-S316 | 0.530 | 13.50 | 0.616 | 15.60 | 1.580 | 40.10 | 19.05 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP12-12-17-S316 | 0.546 | 13.90 | 0.663 | 16.80 | 2.090 | 53.10 | 19.05 | 12 to 17 | 0.058 to 0.109 | 1.5 to 2.8 | |
| CHETP12-15-20-S316 | 0.621 | 15.80 | 0.707 | 18.00 | 1.590 | 40.40 | 19.05 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP14-11-14-S316 | 0.650 | 16.50 | 0.741 | 18.70 | 1.600 | 40.60 | 22.22 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP14-15-20-S316 | 0.746 | 18.90 | 0.832 | 21.10 | 1.620 | 41.10 | 22.22 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 | |
| CHETP16-11-14-S316 | 0.780 | 19.80 | 0.866 | 22.00 | 1.620 | 41.10 | 25.4 | 11 to 14 | 0.083 to 0.120 | 2.1 to 3.0 | |
| CHETP16-12-17-S316 | 0.794 | 20.10 | 0.908 | 23.10 | 2.110 | 53.60 | 25.4 | 12 to 17 | 0.058 to 0.109 | 1.5 to 2.8 | |
| CHETP16-15-20-S316 | 0.871 | 22.10 | 0.957 | 24.30 | 1.630 | 41.40 | 25.4 | 15 to 20 | 0.035 to 0.072 | 0.9 to 1.8 |
