| Product | Dimension H (Hex) (mm) | Dimension L (mm) | Material | Tube O.D. (in) | Tube O.D. (mm) | Unified National Fine Thread (U) | |
| FPC-2T-S316 | 9.50 | 9.50 | Stainless Steel 316 | 1/8 | 3 | 5/16″-24 | |
| FPC-3T-S316 | 11.10 | 9.50 | Stainless Steel 316 | 3/16 | 4 | 3/8″-24 | |
| FPC-4T-S316 | 14.20 | 8.70 | Stainless Steel 316 | 1/4 | 6 | 7/16″-20 | |
| FPC-5T-S316 | 15.80 | 10.30 | Stainless Steel 316 | 5/16 | 8 | 1/2″-20 | |
| FPC-6T-S316 | 17.40 | 11.90 | Stainless Steel 316 | 3/8 | 10 | 9/16″-18 | |
| FPC-8T-S316 | 22.20 | 13.50 | Stainless Steel 316 | 1/2 | 12 | 3/4″-16 | |
| FPC-10T-S316 | 25.40 | 13.50 | Stainless Steel 316 | 5/8 | 16 | 7/8″-14 | |
| FPC-12T-S316 | 31.70 | 16.70 | Stainless Steel 316 | 3/4 | 18|20 | 1 1/16″-12 | |
| FPC-14T-S316 | 34.90 | 15.90 | Stainless Steel 316 | 7/8 | 22 | 1 3/16″-12 | |
| FPC-16T-S316 | 38.10 | 15.90 | Stainless Steel 316 | 1 | 25 | 1 5/16″-12 | |
| FPC-20T-S316 | 50.00 | 19.10 | Stainless Steel 316 | 1-1/4 | 32 | 1 5/8″-12 | |
| FPC-24T-S316 | 57.20 | 23.80 | Stainless Steel 316 | 1-1/2 | 38 | 1 7/8″-12 | |
| FPC-32T-S316 | 75.00 | 30.10 | Stainless Steel 316 | 2 | 50 | 2 1/2″-12 | |
| FPC-2T-BRAS | 9.50 | 9.50 | Brass | 1/8 | 3 | 5/16″-24 | |
| FPC-3T-BRAS | 11.10 | 9.50 | Brass | 3/16 | 4 | 3/8″-24 | |
| FPC-4T-BRAS | 14.20 | 8.70 | Brass | 1/4 | 6 | 7/16″-20 | |
| FPC-5T-BRAS | 15.80 | 10.30 | Brass | 5/16 | 8 | 1/2″-20 | |
| FPC-6T-BRAS | 17.40 | 11.90 | Brass | 3/8 | 10 | 9/16″-18 | |
| FPC-8T-BRAS | 22.20 | 13.50 | Brass | 1/2 | 12 | 3/4″-16 | |
| FPC-10T-BRAS | 25.40 | 13.50 | Brass | 5/8 | 16 | 7/8″-14 | |
| FPC-12T-BRAS | 31.70 | 16.70 | Brass | 3/4 | 18|20 | 1 1/16″-12 | |
| FPC-14T-BRAS | 34.90 | 15.90 | Brass | 7/8 | 22 | 1 3/16″-12 | |
| FPC-16T-BRAS | 38.10 | 15.90 | Brass | 1 | 25 | 1 5/16″-12 | |
| FPC-20T-BRAS | 50.00 | 19.10 | Brass | 1-1/4 | 32 | 1 5/8″-12 | |
| FPC-24T-BRAS | 57.20 | 23.80 | Brass | 1-1/2 | 38 | 1 7/8″-12 | |
| FPC-32T-BRAS | 75.00 | 30.10 | Brass | 2 | 50 | 2 1/2″-12 | |
| FPC-2T-STEL | 9.50 | 9.50 | Carbon Steel | 1/8 | 3 | 5/16″-24 | |
| FPC-3T-STEL | 11.10 | 9.50 | Carbon Steel | 3/16 | 4 | 3/8″-24 | |
| FPC-4T-STEL | 14.20 | 8.70 | Carbon Steel | 1/4 | 6 | 7/16″-20 | |
| FPC-5T-STEL | 15.80 | 10.30 | Carbon Steel | 5/16 | 8 | 1/2″-20 | |
| FPC-6T-STEL | 17.40 | 11.90 | Carbon Steel | 3/8 | 10 | 9/16″-18 | |
| FPC-8T-STEL | 22.20 | 13.50 | Carbon Steel | 1/2 | 12 | 3/4″-16 | |
| FPC-10T-STEL | 25.40 | 13.50 | Carbon Steel | 5/8 | 16 | 7/8″-14 | |
| FPC-12T-STEL | 31.70 | 16.70 | Carbon Steel | 3/4 | 18|20 | 1 1/16″-12 | |
| FPC-14T-STEL | 34.90 | 15.90 | Carbon Steel | 7/8 | 22 | 1 3/16″-12 | |
| FPC-16T-STEL | 38.10 | 15.90 | Carbon Steel | 1 | 25 | 1 5/16″-12 | |
| FPC-20T-STEL | 50.00 | 19.10 | Carbon Steel | 1-1/4 | 32 | 1 5/8″-12 | |
| FPC-24T-STEL | 57.20 | 23.80 | Carbon Steel | 1-1/2 | 38 | 1 7/8″-12 | |
| FPC-32T-STEL | 75.00 | 30.10 | Carbon Steel | 2 | 50 | 2 1/2″-12 |
